EvoFast - DT Swiss 240
Couldn't load pickup availability
Secure payment with
- Rims guaranteed for 2 years
- Fast shipping
- Entirely hand-assembled
Table of weights according to options
| EvoFast - DT Swiss 240 | No options |
| 35/35 mm | 1335 gr. |
| 42/42 mm | 1365 gr. |
| 50/50 mm | 1435 gr. |
| 60/60 mm | 1465 gr. |
Notifiez-moi
IN DETAIL
Rims
- The 2026 EvoFast model is renewed in an improved version with a brand-new design to suit all profiles.
- Its new "wavy" profile improves stiffness and aerodynamics while reducing wind drag, allowing for excellent performance on flat courses. Their low mass is not a disadvantage on climbs.
- Internal width of 24 mm.
- External width of 31 mm for excellent aerodynamics.
- Asymmetric rim to provide greater responsiveness and tension durability.
- Rim: 35, 42, 50, or 60 mm depth, tubeless and tire compatible, disc brake.
- Rim with hooks – Non-hookless
- Compatible tire width: from 28 mm to 35 mm
- Ideal tire width: from 28 mm to 30 mm
- Maximum pressure: 28 mm - 8 bar, 30 mm - 7 bar, 32 mm - 6 bar
- Carbon finish: Satin UD
- 2-year rim warranty
Hubs
DT Swiss 240 hubs. As with the DT Swiss 350, reliability is impeccable. They still feature the infallible 36-tooth ratchet freewheel system, here in its improved EXP version. The bearings are higher end, and the machining is more advanced to achieve a weight reduction of around 75 grams. Disc mounts: 6-bolt or centerlock.
Departments
- 48 Sapim CX-Ray straight-pull bladed spokes, the best compromise between strength, responsiveness, and lightness. Steel lacing optional.
- Nipples with thread-locking technology, to ensure the stability of the assembly over time.
Assembly
Assembly and lacing performed entirely by hand in France in our Annecy workshops. High tension for a very responsive wheel. Even tension and stress-relieved for a wheel that remains very stable over time.
Summary
- Size (wheels): 700c
- Rim depth: 35, 42, 50 or 60 mm (choice of)
- Construction material: carbon
- Tire compatibility: tubeless and inner tube
- Braking: discs
- Disc mounting: centerlock
- Front axle: 12 x 100
- Rear axle: 142 x 100
- Freehub body: XDR, Shimano 10/11/12 speed, Campagnolo
- Internal rim width: 24 mm
- External rim width: 31 mm
- Asymmetrical rim
- Hooked rim – not hookless
- Compatible tire width: 28 mm to 35 mm
- Ideal tire width: 28 mm to 30 mm
- Maximum pressure: 28 mm - 8 bar, 30 mm - 7 bar, 32 mm - 6 bar
- Carbon finish: UD Satin
- Wheels assembled with rim tape and tubeless valves
- Rim guaranteed for 2 years
